Implementing API Gateways in ASP.NET Core: Routing, Aggregation, and Security
Centralize routing, security, and request handling for modern ASP.NET Core microservices
As applications evolve into dozens of independent microservices, managing communication between clients and services becomes increasingly complex. Without a central entry point, clients often need to know where every service lives, how each service authenticates requests, and which endpoints to call. API Gateways solve this problem by acting as a single front door for your applications.
In this guide, we’ll explore how API Gateways work, how to implement them using ASP.NET Core, and how they improve routing, security, scalability, and developer experience in modern distributed systems.
Why Microservices Need a Front Door
Imagine an online shopping application built using microservices.
Instead of one application, you now have:
Product Service
Orders Service
Inventory Service
Payment Service
Shipping Service
Notification Service
If a mobile application communicates directly with every service, several problems appear.
The client must know:
Where each service lives
Which URLs to call
Which authentication tokens are required
Which service owns which data
Every new microservice increases complexity.
This quickly becomes difficult to maintain.
What Is an API Gateway?
An API Gateway sits between clients and your microservices.
Instead of calling services directly, every request goes through the gateway.
Mobile App
Web App
Desktop App
│
▼
API Gateway
│
┌──────┼────────┐
▼ ▼ ▼
Orders Products PaymentsThe gateway becomes the single public entry point.
Clients only need to know one address.
Why API Gateways Matter
API Gateways simplify communication.
Instead of exposing every internal service, the gateway handles:
Routing
Authentication
Authorization
Rate limiting
Request aggregation
Logging
Monitoring
Response transformation
Microservices remain focused on business logic.
The gateway handles cross-cutting concerns.
Understanding Request Routing
The primary responsibility of an API Gateway is routing.
For example:
/api/products
│
▼
Product Service
/api/orders
│
▼
Orders Service
/api/payments
│
▼
Payment ServiceClients don’t need to know where services are hosted.
The gateway forwards requests automatically.
Building an API Gateway with ASP.NET Core
ASP.NET Core provides several options.
One of the most popular is YARP (Yet Another Reverse Proxy), developed by Microsoft.
Install:
dotnet add package Yarp.ReverseProxyConfiguring YARP
Register the reverse proxy.
builder.Services
.AddReverseProxy()
.LoadFromConfig(
builder.Configuration
.GetSection("ReverseProxy"));Then enable it.
app.MapReverseProxy();Your gateway is now ready to forward requests.
Configuring Routes
Example configuration:
{
"ReverseProxy": {
"Routes": {
"products": {
"ClusterId": "products",
"Match": {
"Path": "/products/{**catch-all}"
}
}
}
}
}Clients continue calling one API while YARP forwards traffic to the correct service.
Request Aggregation
Sometimes a client needs data from multiple services.
Imagine loading a product page.
The application needs:
Product details
Inventory
Reviews
Pricing
Without a gateway:
The browser makes four separate requests.
With aggregation:
The browser makes one request.
The gateway gathers information from multiple services before returning a single response.
This reduces network traffic and improves performance.
Example Aggregation Flow
Client
│
▼
Gateway
├── Product Service
├── Inventory Service
├── Review Service
└── Pricing Service
│
▼
Combined ResponseThe client receives one complete response.
Authentication at the Gateway
One of the biggest advantages of an API Gateway is centralized authentication.
Instead of every service validating JWT tokens independently, the gateway performs the initial authentication.
Example:
builder.Services
.AddAuthentication()
.AddJwtBearer();Only authenticated requests reach internal services.
This simplifies service development.
Authorization
Authentication identifies users.
Authorization determines what they can access.
Policy-based authorization works well inside gateways.
Example:
[Authorize(Policy = "Orders.Read")]Unauthorized requests are rejected before reaching downstream services.
Rate Limiting
Gateways are an ideal location for rate limiting.
ASP.NET Core includes built-in support.
Example:
builder.Services.AddRateLimiter(options =>
{
options.AddFixedWindowLimiter(
"api",
limiter =>
{
limiter.PermitLimit = 100;
limiter.Window =
TimeSpan.FromMinutes(1);
});
});Rate limiting protects services from abuse.
Response Caching
Frequently requested data can be cached.
Instead of contacting the Product Service repeatedly, the gateway serves cached responses.
Benefits include:
Faster responses
Reduced backend load
Lower infrastructure costs
Caching should be applied carefully to avoid serving stale data.
Load Balancing
A Product Service may run multiple instances.
Gateway
│
┌─┼─────────────┐
▼ ▼ ▼
Instance A
Instance B
Instance CThe gateway distributes traffic across available instances.
Users experience higher availability without knowing multiple servers exist.
Service Discovery
Microservices often change location.
Containers restart.
Pods move.
New instances appear.
Instead of hardcoding addresses, the gateway integrates with service discovery solutions.
Examples include:
Kubernetes
Consul
Azure Container Apps
Requests always reach healthy instances.
Circuit Breakers
If a downstream service fails, the gateway should avoid repeatedly sending requests.
Circuit breakers temporarily stop traffic to unhealthy services.
This improves overall system stability.
It also complements the resilience strategies we explored in previous articles.
Logging Requests
Every request passes through the gateway.
This makes it an excellent place to capture:
Request paths
Response codes
Processing times
Client IP addresses
These logs become valuable for troubleshooting.
Distributed Tracing
The gateway also plays an important role in observability.
Using OpenTelemetry, it can:
Start trace spans
Propagate trace context
Record latency
Capture downstream service performance
This connects directly with our earlier article on distributed tracing.
API Versioning
Gateways simplify API evolution.
Clients may continue using:
/api/v1/ordersWhile newer clients use:
/api/v2/ordersThe gateway routes requests appropriately without exposing internal service complexity.
Security Benefits
The gateway strengthens security by:
Hiding internal services
Centralizing authentication
Applying authorization policies
Enforcing HTTPS
Performing request validation
Blocking malicious traffic
Internal services remain inaccessible from the public internet.
Common Mistakes
Avoid making the gateway responsible for business logic.
The gateway should coordinate requests.
Business decisions belong inside services.
Also avoid:
Creating a single massive gateway
Hardcoding routes
Ignoring monitoring
Forgetting rate limiting
Bypassing authentication
A lightweight gateway is easier to maintain.
Real-World Example
Imagine an airline booking platform.
Customers use one mobile app.
Behind the scenes the gateway communicates with:
Flight Service
Booking Service
Payment Service
Loyalty Service
Notification Service
The mobile app makes a single request.
The gateway handles routing, authentication, aggregation, and response formatting.
The customer experiences one seamless interaction despite multiple backend services working together.
How This Fits Your ASP.NET Core Journey
Our recent articles explored:
Microservices
Zero Trust Architecture
Data Protection
Advanced Authorization
Internal Developer Platforms
API Gateways bring these ideas together.
They become the secure front door through which every request enters your distributed system.
They enforce security, simplify communication, improve observability, and create a better experience for both developers and users.
Closing Thoughts
As applications continue moving toward microservices, API Gateways become an essential architectural component.
They reduce client complexity, centralize security, simplify routing, and provide a single location for cross-cutting concerns such as authentication, logging, caching, and monitoring.
ASP.NET Core, together with Microsoft’s YARP project, provides an excellent foundation for building lightweight, high-performance API Gateways that scale with modern cloud-native applications.
Rather than exposing dozens of services directly, let your gateway become the intelligent front door that protects, organizes, and simplifies your entire platform.
